The Bently Nevada 3500/22-01-00 is a Standard Transient Data Interface (TDI) reference for the 3500 Machinery Protection System
Marca :
Bently NevadaNúmero de parte :
3500/22-01-00Peso :
0.26 kgDimensión :
3.1 × 19 × 12.8 cmPaís de origen :
USACódigo hs :
8537101190Descripción :
Standard Transient Data Interface
|
3500/22-01-00 |
Contact |
|
Mobile / WhatsApp |
|
|
Email |
Product Overview
The Bently Nevada 3500/22-01-00 is a Standard Transient Data Interface (TDI) reference for the 3500 Machinery Protection System. The TDI combines rack-interface functions with machinery-data collection, creating the connection between the 3500 rack and compatible configuration or condition-monitoring software. Installed in Slot 1 beside the rack power supplies, the TDI works with 3500 M-series monitor modules to collect static values and waveform-related data. It supports reliable access to machinery information without forming part of the critical protection path.
Order Number Breakdown
Position
Code
Description
Product Series
3500/20
Bently Nevada 3500 Rack Interface Module
Rack Interface Type
1
Standard RIM for standard monitoring applications
I/O Module Type
2
I/O module with RS232/RS422 interface
Approval Option
CN
Country-specific approvals option
Technical Information
Manufacturer: Bently Nevada
Product Line: 3500 Machinery Protection System
Ordering Number: 3500/22-01-00
Product Type: Standard Transient Data Interface (TDI)
Host Communication: Ethernet through the selected TDI I/O module
Power Consumption: 10.5 W
Operating Temperature: -30°C to +65°C
Storage Temperature: -40°C to +85°C
Relative Humidity: 95%, non-condensing
Benefits&Features
Feature
Benefit
Primary rack interface
Provides the configuration and communication connection for one 3500 rack.
Standard RIM design
Matches standard machinery-monitoring applications.
RS232/RS422 serial I/O
Supports local serial access and longer-distance RS422 links.
38.4 k baud communication
Supports efficient configuration and machinery-data retrieval.
Front-panel RS232 port
Enables local connection to the rack.
Long RS422 cable capability
Supports RS422 cable lengths up to 1200 m (4000 ft).
Rack status LEDs
Shows RIM health, communication activity, Trip Multiply and configuration status.
Rack reset function
Clears latched alarms and Timed OK Channel Defeat functions.
Selectable rack addressing
Supports up to 63 rack addresses.
I/O OK relay
Provides a rack-status signal for external annunciation.
Application Areas
• Central data interface for Bently Nevada 3500 monitoring racks
• Machinery condition monitoring and diagnostic data collection
• Steady-state and transient waveform acquisition
• 3500 rack configuration and communication with host software
• Rotating-equipment monitoring systems using compatible 3500 M-series monitors
Frequently Asked Questions
1. What is the function of the 3500/22-01-00?
It is a Standard Transient Data Interface reference used to link a 3500 monitoring rack with compatible configuration and machinery-condition monitoring software.
2. Where is the TDI installed in a 3500 rack?
The TDI occupies Slot 1, adjacent to the rack power supplies.
3. What data can the TDI collect?
Static data capture is standard. With an optional Dynamic Data Enabling Disk, the TDI can also collect dynamic and high-resolution transient waveform data.
4. Does 3500/22-01-00 define the Ethernet I/O type?
The current Baker Hughes ordering structure includes a separate I/O-module field. This shortened reference confirms the Standard TDI type, but the selected copper or fiber Ethernet I/O version should be confirmed from the unit label.
