SIMATIC S7-1200 · CM 1242-5

6GK7242-5DX30-0XE0

The 6GK7242-5DX30-0XE0 is a Siemens SIMATIC S7-1200 communication module for connecting an S7-1200 station to PROFIBUS as a DP slave.

NETWORKPROFIBUS DP
ROLEDP slave
CONNECTOR9-pin Sub-D
MODULE TYPECM 1242-5
MANUFACTURERSiemens
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Pregunte ahora
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
SIEMENS ● PROFIBUS DP SLAVE MODULE
SIMATIC S7-1200 CM 1242-5

6GK7242-5DX30-0XE0

CM 1242-5

PROFIBUS DP slave

MODULE ROLE
6GK7242-5DX30-0XE0 is a SIMATIC S7-1200 communication module that connects an S7-1200 station to a PROFIBUS network as a DP slave.
CONFIGURATION NOTE
For 6GK7242-5DX30-0XE0, Siemens specifies PROFIBUS DP slave operation; confirm bus address, transmission rate, GSD configuration, connector and termination before commissioning.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the order number identifies this module

6GK7242
Product familySIMATIC S7-1200
PROFIBUS MODULE
5DX30
CM 1242-5
0XE0
Order suffix
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

SIMATIC S7-1200 ↗
CM 1242-5 PROFIBUS DP SLAVE MODULE

Engineering data at a glance

Click “+” to expand more specifications.

PACK LENGTH4.0 cm
PACK WIDTH12.0 cm
PACK HEIGHT12.5 cm
NET WEIGHT0.172 kg
Official Siemens product data.
Official product verification Verify the complete order number 6GK7242-5DX30-0XE0and PROFIBUS role, bus address, connector, GSD configuration, transmission rate and CPU compatibility against the current official Siemens datasheet before ordering.
General Information −
BrandSiemens
Part number6GK7242-5DX30-0XE0
Product typeCM 1242-5 PROFIBUS DP Slave Module
Product familySIMATIC S7-1200
Mounting styleDIN rail
Engineering softwareSTEP 7 in TIA Portal
PROFIBUS Communication ＋
NetworkPROFIBUS DP
Station roleDP slave
Electrical interface9-pin Sub-D PROFIBUS connection
Module and Ordering Data ＋
Communication roleConnect S7-1200 as DP slave
Product familyCM 1242-5
Article statusActive Product
Packaging quantity1 piece
Lifecycle statusActive Product
Environment and Certification ＋
Packaging dimensions and net weight: 4.0 cm × 12.0 cm × 12.5 cm; 0.172 kg.
Source: Siemens official SiePortal product data and technical datasheet for 6GK7242-5DX30-0XE0.
FAQ

Questions Buyers Ask Most

What is 6GK7242-5DX30-0XE0 used for?＋

6GK7242-5DX30-0XE0 connects a SIMATIC S7-1200 station to an existing PROFIBUS DP network where the S7-1200 operates as an intelligent DP slave.

What PROFIBUS role does 6GK7242-5DX30-0XE0 support?＋

6GK7242-5DX30-0XE0 provides DP slave operation for exchanging configured cyclic data with a PROFIBUS DP master.

Does 6GK7242-5DX30-0XE0 work as a PROFIBUS DP master?＋

6GK7242-5DX30-0XE0 is designed as a PROFIBUS DP slave module; applications requiring master functionality need the appropriate Siemens master module.

What must be configured before using 6GK7242-5DX30-0XE0 ?＋

6GK7242-5DX30-0XE0 requires a unique PROFIBUS address and matching GSD/data configuration, together with correct bus cable, termination and transmission-rate settings.

What are the packaging dimensions and net weight of 6GK7242-5DX30-0XE0 ?＋

6GK7242-5DX30-0XE0 has official packaging dimensions of 4.0 × 12.0 × 12.5 cm and a net weight of 0.172 kg.

Is 6GK7242-5DX30-0XE0 an active Siemens product?＋

6GK7242-5DX30-0XE0 is listed by Siemens as an Active Product, supplied as one piece per package.

What information is needed to quote 6GK7242-5DX30-0XE0 ?＋

6GK7242-5DX30-0XE0 should be quoted with the full order number, S7-1200 CPU, DP master type, bus speed, connector and cable requirements, quantity and delivery destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Manuals and Official References for
6GK7242-5DX30-0XE0

Official Siemens documentation for the SIMATIC S7-1200 CM 1242-5 PROFIBUS DP slave communication module.

SIMATIC S7-1200 CM 1242-5

Siemens technical datasheet for 6GK7242-5DX30-0XE0, including PROFIBUS role, interfaces, lifecycle, packaging dimensions and net weight.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Technical statements on this product page are based on publicly available official Siemens manufacturer documentation.

S7-1200 PROFIBUS RELATIONSHIP

How CM 1242-5 Fits into the SIMATIC S7-1200 System

Siemens is the brand; SIMATIC S7-1200 is the product family; and 6GK7242-5DX30-0XE0 is the CM 1242-5 PROFIBUS DP slave module.

Siemens · BRAND
SIMATIC S7-1200PLC FAMILY · AUTOMATION SYSTEM
PROFIBUS DP SLAVE MODULE

CM 1242-5

CM 1242-5 integrates an S7-1200 station into a PROFIBUS network as a DP slave.

ENGINEERING

STEP 7 in TIA Portal

STEP 7 in TIA Portal is used to configure the CM 1242-5, DP address and cyclic data exchange.

PROFIBUS NETWORK

DP SLAVE CONNECTIVITY

The module provides PROFIBUS DP slave communication for integration beneath a compatible DP master.

System relationship: verify DP role, GSD configuration, bus address, cable, termination and CPU compatibility.
APPLICATION AREAS

Application mind map for the SIMATIC S7-1200 CM 1242-5

S7-1200 as DP SlaveExchange cyclic I/O data with a plant PROFIBUS master
Legacy Network IntegrationAdd an S7-1200 station to an installed PROFIBUS DP network
APPLICATION CENTER CM 1242-5 PROFIBUS DP slave module
Machine Subsystem InterfaceExpose configured machine data to a supervisory DP master
Distributed AutomationCoordinate an S7-1200 controller with higher-level PROFIBUS control
