 /MEAN WELL SP-240-24 240W 24V 10A Single Output AC-DC Power Supply
MEAN WELL SP-240-24 240W 24V 10A Single Output AC-DC Power Supply
MEAN WELL SP-240-24 240W 24V 10A Single Output AC-DC Power Supply
MEAN WELL SP-240-24 240W 24V 10A Single Output AC-DC Power Supply

MEAN WELL SP-240-24 240W 24V 10A Single Output AC-DC Power Supply

MEAN WELL SP-240 · AC-DC POWER

SP-240-24

The SP-240-24 is a MEAN WELL SP-240 series enclosed single-output AC-DC power supply rated 24 V DC, 10 A and 240 W with active PFC.

OUTPUT VOLTAGE24 V DC
OUTPUT CURRENT10 A
RATED POWER240 W
EFFICIENCY87% TYP.
MANUFACTURERMEAN WELL
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Pregunte ahora
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
MEAN WELL ● SINGLE OUTPUT AC-DC POWER SUPPLY
MEAN WELL SP-240 SERIES

SP-240-24

24 V DC · 10 A OUTPUT

240 W · ACTIVE PFC

MODULE ROLE
SP-240-24 is a MEAN WELL SP-240 series enclosed single-output AC-DC power supply rated 24 V DC, 10 A and 240 W with active PFC.
CONFIGURATION NOTE
For SP-240-24, the official SP-240 specification lists 88–264 V AC or 124–370 V DC input, 24 V DC nominal output, 10 A rated current, 240 W power and 87% typical efficiency
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the order number identifies this module

SP-240
Product familyMEAN WELL SP-240 Series
SINGLE OUTPUT AC-DC POWER SUPPLY
SP-240-24
Single Output AC-DC Power Supply
SP-240-24
Manufacturer part number
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

MEAN WELL MEAN WELL SP-240 Series ↗
SP-240-24 SINGLE OUTPUT AC-DC POWER SUPPLY

Engineering data at a glance

Click “+” to expand more specifications.

OUTPUT VOLTAGE24 V DC
OUTPUT CURRENT10 A
RATED POWER240 W
EFFICIENCY87% TYP.
Official MEAN WELL product data.
Official product verification Verify the complete order number SP-240-24 and confirm the exact suffix, nameplate, hardware revision, connector layout and host-system compatibility before ordering.
General Information −
BrandMEAN WELL
Part numberSP-240-24
Product typeSingle Output AC-DC Power Supply
Product familyMEAN WELL SP-240 Series
ConstructionEnclosed single-output supply
CoolingBuilt-in DC fan with fan control
INPUT & OUTPUT ＋
AC input range88–264 V AC
DC input range124–370 V DC
Output adjustment20–28 V DC
PERFORMANCE & MECHANICAL ＋
Typical efficiency87%
Ripple and noise150 mV p-p maximum
Dimensions190 × 93 × 50 mm
Operating temperature−20 to +70 °C
Power factor>0.95 at 230 V AC; >0.98 at 115 V AC
DOCUMENTATION & ORDER CHECK ＋
Reference: MEAN WELL official SP-240 series specification..
Source: MEAN WELL official SP-240 series specification.
FAQ

Questions Buyers Ask Most

What is SP-240-24 used for?＋

SP-240-24 provides regulated 24 V DC power for industrial control loads up to 10 A.

What input range does SP-240-24 accept?＋

SP-240-24 accepts 88–264 V AC or 124–370 V DC.

How much output power can SP-240-24 deliver?＋

SP-240-24 is rated for 24 V DC, 10 A and 240 W output.

What is the adjustment range of SP-240-24 ?＋

SP-240-24 can be adjusted from 20 V to 28 V DC.

What efficiency is specified for SP-240-24 ?＋

SP-240-24 has 87% typical efficiency at its rated output.

What enclosure space is required for SP-240-24 ?＋

SP-240-24 measures 190 × 93 × 50 mm; allow space for wiring and cooling.

What information is needed to quote SP-240-24 ?＋

SP-240-24 should be quoted with the full model, quantity and destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Manuals and Official References for
SP-240-24

Official MEAN WELL documentation for the SP-240-24 240 W single-output power supply.

SP-240 Series 240W Single Output Power Supply

Official MEAN WELL SP-240 specification covering output ratings, input range, PFC, efficiency, protection, dimensions and environmental data.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Technical statements on this page are based on the official MEAN WELL SP-240 series specification.
