ABB · AC500-ECO ANALOG INPUT MODULE

AI563 1TNE968902R1103

The AI563 1TNE968902R1103 is an ABB analog input module with four thermocouple inputs for AC500-eCo and S500-eCo I/O systems.

MANUFACTURERABB
MODELAI563
ORDER NUMBER1TNE968902R1103
STATUSOFFICIAL ABB PRODUCT DATA
MANUFACTURERABB
PRODUCT TYPE4-channel thermocouple analog input module
CONDITION / WARRANTYOriginal New · One-Year Warranty
VERIFICATION● Verify thermocouple type, terminal block and channel wiring before replacement
REQUEST A QUOTE
Pregunte ahora
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
ABB ● AC500-ECO ANALOG INPUT MODULE
AC500-ECO ANALOG INPUT MODULE

AI563 1TNE968902R1103

OFFICIAL ABB PRODUCT DATA

4 AI · thermocouple input · ±80 mV

PRODUCT ROLE
AI563 1TNE968902R1103 is an ABB analog input module with four thermocouple inputs. ABB lists order number 1TNE968902R1103 for model AI563 in the AC500-eCo / S500-eCo I/O family.
INSTALLATION CHECK
Confirm the complete order number, supported thermocouple type, terminal block, channel wiring and safe isolation before replacement.
WANT THE BEST PRICE?

Frida

Sales Leader 🏆
MODEL IDENTIFICATION

How AI563 1TNE968902R1103 is identified

ABB is the manufacturer, AI563 is the module model, and 1TNE968902R1103 is the complete ABB order number. ABB documents AI563 as an analog input module with four thermocouple inputs.

ABB
Manufacturer

ABB automation product

AI563
Module model

4-channel thermocouple AI

1TNE968902R1103
Order number

Exact catalog reference

OFFICIAL ABB PRODUCT DATA

Technical Specifications

AC500-eCo / S500-eCo I/O
AI563 · 1TNE968902R1103

Engineering data at a glance

Official ABB catalog data lists AI563 as a four-channel thermocouple analog input module.

INPUT CHANNELS4 AI
THERMOCOUPLESS, T, R, E, N, K, J
INPUT RANGE±80 mV
WEIGHT0.123 kg
Verify the complete order number, thermocouple type, terminal block and field wiring before replacement.
GENERAL INFORMATION＋
ManufacturerABB
ModelAI563
Order number1TNE968902R1103
Product typeAnalog input module
SIGNAL & PERFORMANCE＋
Input channels4 AI
Supported thermocouplesS, T, R, E, N, K, J
Input voltage range±80 mV
Resolution16 bits including sign
SYSTEM & CONNECTION＋
I/O familyAC500-eCo / S500-eCo
Terminal blocksTA565-9 and TA565-11
PHYSICAL DATA＋
Weight0.123 kg
FAQ

Questions Buyers Ask Most

What type of product is AI563 1TNE968902R1103?+

AI563 1TNE968902R1103 is an ABB analog input module with four thermocouple input channels.

Which thermocouple types are supported by AI563 1TNE968902R1103?+

AI563 1TNE968902R1103 supports thermocouple types S, T, R, E, N, K and J.

What input voltage range applies to AI563 1TNE968902R1103?+

AI563 1TNE968902R1103 has an input voltage range of ±80 mV.

What resolution is listed for AI563 1TNE968902R1103?+

AI563 1TNE968902R1103 provides 16-bit resolution including sign.

Which I/O family uses AI563 1TNE968902R1103?+

AI563 1TNE968902R1103 belongs to the ABB AC500-eCo / S500-eCo I/O family.

Which terminal blocks are listed for AI563 1TNE968902R1103?+

AI563 1TNE968902R1103 is listed with TA565-9 and TA565-11 terminal blocks.

What should be checked before ordering AI563 1TNE968902R1103?+

AI563 1TNE968902R1103 should be matched by complete order number, thermocouple type, terminal block and installed channel wiring.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Official Datasheet and References for
AI563 1TNE968902R1103

ABB PLC Automation catalog data lists AI563, order number 1TNE968902R1103, as a four-channel thermocouple analog input module.

ABB AI563 1TNE968902R1103

The official catalog provides the exact order number, supported thermocouple types, input range, resolution, terminal-block information and weight for AI563.

OPEN OFFICIAL ABB MANUAL ↗

Contact to Get Support

Send the complete order number, quantity, thermocouple type and installed-system details.

✉ EMAIL
sales5@mooreplc.comWHATSAPP
+86 153 5940 8275

Official source: ABB PLC Automation main catalog, document 3ADR020077C0204.

MODEL IDENTIFICATION

How AI563 1TNE968902R1103 fits into the ABB AC500-eCo system

ABB is the manufacturer, AI563 is the complete module model, and 1TNE968902R1103 is the exact order number. The product is a four-channel thermocouple analog input module.

BRAND / PLATFORMABB AC500-eCo / S500-eCo
→
COMPLETE MODELAI563
→
ORDER NUMBER1TNE968902R1103
PRODUCT TYPEThermocouple analog input module
CHANNEL CAPACITY4 analog input channels
SIGNAL TYPESThermocouples S, T, R, E, N, K and J
SELECTION CHECKMatch terminal block and installed wiring
APPLICATION AREAS

Where AI563 is applied

Industrial temperature measurementAcquires thermocouple temperature signals in machinery and process installations.
Process monitoringProvides four temperature input channels for monitoring and control tasks.
APPLICATION CENTERAI563Four-channel thermocouple signal acquisition
AC500-eCo control systemsIntegrates thermocouple measurements into the ABB AC500-eCo / S500-eCo I/O architecture.
Retrofit and spare replacementUsed when the exact AI563 order number, terminal block and field wiring match the installed station.
