Marca :
HoneywellNúmero de parte :
900ES1-0100Peso :
0.35 kgDimensión :
137 mm × 35.6 mm × 151.7 mmPaís de origen :
USACódigo hs :
8537101190Descripción :
Communication Module
Contact Our Manager Frida to Get Price:
Phone/Whatsapp: +86 15359408275
Email: sales5@mooreplc.com
Material number:
900ES1-0100
Description:
Serial Communication Module for ControlEdge™ PLC
4-port serial communications module: 2 × RS232 ports and 2 × RS485 ports
Supports Modbus Serial communication protocol (ASCII Master/Slave, RTU Master/Slave) and User Defined Protocol
Extended temperature range (-40 to 70 °C)
The 900ES1-0100 is a serial communication module that provides versatile serial connectivity for the ControlEdge. It features two RS232 ports and two RS485 ports with galvanic isolation. The module supports Modbus RTU/ASCII protocols and allows user-defined protocol implementation. It is designed for extended temperature operation and can be installed in any I/O slot of the ControlEdge 900 platform.
Technical Data:
Galvanic isolation:2000 V DC
Maximum slave devices per RS485 port:32
Maximum communication modules per CPM:6
Operating temperature:-40 to 70 °C
Storage temperature:-40 to 85 °C
Baud rate:300 bps to 115200 bps (adjustable)
Flow control:None, RTS-CTS, RTS
Parity:None, Odd, Even
Data bits:7, 8 (7 not supported on Modbus RTU protocol)
Stop bits:1, 2
Maximum length of User Defined Protocol:532 Bytes
Accessories:
900CP1-0200:Control Processor Module v1
900CP1-0300:Control Processor Module, Ext. Temp (-40 to 70 °C)
900SP1-0200 / 900SP1-0300:Expansion Processor Module
900U01-0100:Universal I/O Module
900P01-0701:Power supply, AC-DC, 41W, Ext. Temp (-40 to 70 °C)
900PSM-0200:Redundant Power Status Module, Ext. Temp
FAQ about us
Q:Is your product new or refurbished?
A: All our products are 100% original and brand new, and they come with a one-year warrant
Q: How long will it take to receive the goods if I place an order now?
A: Once we receive your payment, the product will be shipped immediately. Delivery from China typically takes 3–5 business days depending on the courier service.
Q: Could you offer a discount?
A: Yes. Please contact Frida to receive the best price and available discounts
Q: Do you have a datasheet available?
A: Yes, the datasheet is available.
Buying Note
Payment Terms:100% TT in advance
Incoterms:EXW, DAP
Availability of Datasheet / User Manual: Yes
Shipping:
(1)If you have a DHL/FEDEX/UPS/CHIRLINE/Aramex account, you can come to our company to pick up the goods directly.
(2)Let us ship goods for you.
(3)We can ship to your forwarder in China
